< 750kg Scale Pyrolysis Unit
KJ-PU750kg
The pyrolysis unit is with the newest pyrolysis technology. It can converting waste tire and plastic to oil.It not only solves the problem of waste plastic polluting the environment, but also brings benefits to people. The pyrolysis plant have the advantages of environmental friendly ,long service life and energy saving.
| Supply Scope | |
| Part | Quantity |
| PYROLYSIS REACTOR | |
| Pyrolysis reactor Internal dimension Ф1200x3000 (mm) |
1 |
| Gear of reactor | 1 |
| Reducer | 1 |
| Motor to reducer 2.2kw | 1 |
| CONDENSING SYSTEM | |
| Condenser pipe | 1 |
| Square box condenser | 1 |
| Oil-gas purification device | 1 |
| Oil-water separator | 1 |
| Square oil tank | 2 |
| Oil pump | 1 |
| Syngas collector | 1 |
| HEATING SYSTEM | |
| Oil burner | 2 |
| Gas burner | 1 |
| Blower 3kw | 1 |
| EMISSION CONTROL SYSTEM | |
| Stainless steel deduster with internal ceramic filters | 1 |
| Water pump of deduster 1.5kw | 1 |
| Draught fan | 1 |
| Base of chimney (stainless steel) | 1 |
| Chimney Ф273x6000 (mm) | 1 |
| OFFLOADING SYSTEM | |
| Carbo black offloader built-inside reactor | 1 |
| OTHERS | |
| Pressure gauge | 2 |
| Thermometer | 7 |
| Alarm | 1 |
| Thermocouple | 1 |
| Approx. Oil Yield of Different Raw Materials | |
| PP(microwave oven food box/yogurt bottles,etc.) | 50%~75% |
| PE (Plastic film / plastic wrap) | 50%~75% |
| PS (fast food boxes / instant noodle boxes) | 50%~75% |
| ABS (Engineering plastics) | 40% |
| Leftovers of paper | Wet 15~20% , Dry 60% |
| House garbage | 35-50% |
| Plastic cable | 80% |
| Plastic bags | 50% |
| Submarine cable | 75% |
| Rubber cable | 35% |
| Soles | 30% |
| Big tires | 45%~50% |
| Small tires | 35%~40% |
| PVC (raincoat/building materials.etc.) | Not applicable |
| PET (mineral water bottles/sodas beverage bottles) | Not applicable |
Final Products Final Products and Application and Application
| Products | Application |
| 45%~50% Pyrolysis oil (Tire oil/Plastic oil) | 1.Add it into heavy oil generators to produce electricity. 2.Be used as heating material in ceramic factory, glass factory, power plants, steel making factory, boiler factory,etc. Sell it into oil refining factory for further processing. |
| 25%~30% Carbon black | 1.Sell it into coal briquette factory directly, but with cheap price. 2.Make it into carbon black pellets or briquettes as fuel for burning. Further processing it into color master batch, and then sell it into plastic factory as basic material to make pipes, cable jacket,etc. |
| 15%~20% Steel wire | Sell it into iron and steel factory directly |
| 5%~10% Waste gas | Recycle it into furnace as fuel for heating the reactor |
Waste to wealth, green and environmental.We are on the way!
